PL800CNC.

PL800CNC

Out of stock

Complete base machine with electric motor and hydraulic circuit.

Separate console with CNC computerized control and weld printing.

Two day pivoting heads. 800mm with hydraulic opening. Reductions for 710mm clamps.

Two pivoting heads of diam. 630mm with hydraulic opening. Reductote inserts of 315, 355, 400, 450, 500, 560mm.

Electric milling machine and heating mirror electronically adjustable and coated with PTFE.

SKU: PL800CNC Categories: ,

Description

Technical specifications

ELECTRICAL DATA
Voltage 400 V
Frequency 50 Hz
Poténcia machine 50 Hz
Heating element IP 44 18 Kw
Refresher IP 44 1.5 Kw 2800 rpm
Hydraulic Unit IP 44 2.5 Kw
HYDRAULIC DATA
Maximum working pressure 140 bar
Cylinders Selection 4.71 cm2
Bomb 6.7 l/min 1400 gpm
Hydraulic oil ISO 68
Deposit 25 l
MECHANICAL DATA
Transmission system Chain
Maximum carriage stroke 320 mm
DIMENSIONS
Basic Machine 3500x1700x3000 mm
PESOS
Basic Machine 4000 Kg

Realizar consulta..
