TRACSTAR28.

TRACSTAR28

Out of stock

McElroy fusion machines will fuse tube sizes from 2″ IPS – 8″ DIPS (63mm – 225mm) at the back end. They come in multiple model configurations to ensure your tube melting needs are met.

  • It offers a self-contained and self-propelled tracked vehicle that can face gradients of up to 30%.
  • Ease of maneuver and its gains in productivity.
  • It allows automated control and monitoring of heating, impregnation, melting and cooling cycles.
  • It has an interbuilt data log function that keeps a record of each fusion joint, allowing you to check the integrity of the joints.
  • They include the interchangeable McElroy No.28 four-jaw carriage, which can be easily removed to merge into the trench. In the case of very narrow installations.
  • The external fixed jaw and skid can be removed from the carriage, turning it into a 3-jaw carriage for an even more compact melting unit.
  • Several of these units offer saddle melting capability in the form of a Combination Unit (UC) that allows the fusion of branch saddles up to 8″ DIPS (225mm) into main pipe of any size.
SKU: TRACSTAR28 Categories: ,

Description

Technical specifications

CAPACITY
Fuses size tubes: 2″IPS – 8″DIPS (63mm – 225mm)
WEIGHT
Machine: 1320 lbs (598.7Kg)
4 Gag cart configuration: 219 lbs (99.3Kg)
4 CU jaw carriage configuration: 247 lbs (112Kg)
3 Jaw carriage configuration: 140 lbs (63.5Kg)
3 CU jaw carriage configuration: 168 lbs (76.2Kg)
Face: 37 lbs (16.8Kg)
Heater: 21 lbs (9.5Kg
HYDRAULIC SYSTEM
System pressure: 1800 PSI (124 BAR) Max.
Hydraulic tank capacity: 8 Gallons (30.28 Liters)
ELECTRIC
Scribe: None, self-contained
AC Output (Non-Automated Only) 2 Receptacles 120V & 240V 60 Hz, 15 Amp
ENGINE
Engine Type: 11 HP Air-cooled
Fuel type: Petrol
Fuel tank capacity: 5 Gallons (18.92 Liters)
Tank operating capacity: 8 Hours
CHASSIS
Frame: Welded steel pipe construction
MOBILITY
With caterpillars: Rubber caterpillars
Transportation: Self-propelled, fits in a long-bed truck
Vehicle speed: 1.0 Mph max.
Elevation: Elevation points and elevation assembly
GUARANTEE
Term: 3 years
