PT500

Out of stock

The PT500 is a machine for welding pipes and fittings in PE, PP, PVDF and other thermoplastics.
The complete PT500 equipment is supplied with: basic machine diameter 500, detachable heating mirror coated in PTFE, detachable electric cooler and electrohydraulic motor, clamp for accessories diameter 500mm and set of light alloy reducing inserts diameters 200, 225, 250, 280, 315, 355, 400 and 450mm.
New Beep-Beep system for anchoring the inserts, the screws are over! With a simple click, you can change the reductions, gaining comfort and time.
All Tecnodue PT model machines are prepared to use the LDU system. Reader and printer of the welding data, putting the tube that we are going to weld tells us the parameters to follow and at the end prints us a report indicating if the welding is correct or not.
Range: 200 – 500mm

Description

Technical specifications

OPERATING DATA
Ambient temperature 0… 50ºC
Humidity 95 RH%
Temp.. transport and storage -10… 60ºC
ELECTRICAL DATA
Voltage 230 V
Frequency 50 Hz
Machine power 7.7 kW 34 A
Heating mirror IP 54 5.88 KW
Refresher IP 20 1.1 KW
Hydraulic unit IP 44 0.74 KW
HYDRAULIC DATA
Maximum working pressure 140 bar
Cylinders Selection 5.89 cm2
Maximum force 14,13cm2
Pressure 0 – 160 bar
Scale precision manometer CI 1.0
Volumetric capacity of the pump 1.2 cm3/rev.
Capacity 3.36 l/min
Hydraulic oil ISO 46
Deposit 1.5 l
MECHANICAL DATA
Transmission system Chain
Maximum carriage stroke 270 mm
Scroll bar diameter 40 mm
Distance between cylinders 640 mm
DIMENSIONS
Basic machine 1495x930x870 mm
Refresher 555x850x190 mm
Heating mirror 690x65x820 mm
Hydraulic unit 480x320x270 mm
Mirror and Refractor Support 670x655x510 mm
WEIGHT
Basic machine 171 kg
Refresher 69 kg
Heating mirror 27 kg
Hydraulic unit 28 kg
Mirror and Refractor Support 31 kg
Transport box 145 kg
Lide holder plate 33kg
Complete set of Inserts 144 kg
