PL125

Out of stock

The PL125 is a basic machine for pipe welding and elbow construction up to 125mm in Polyethylene (PE) and Polypropylene (PP).

With the 125mm pivot clamps, you can make welds of different diameters at an angle with a maximum of 30º per weld. It is distinguished from the others by its great maneuverability and easy handling. In addition to its just 16 Kg and its small size.
PL125 is composed of:

  • Basic machine with movement of the cart through the steering wheel.
  • Two main clamps of 125mm (with max. rotation angle of 30º).
  • Reductions of 25, 32, 40, 50, 63, 75, 90 and 110mm.
  • Electric grinder with safety switch.
  • PTFE mirror with adjustable temperature.
SKU: PL125 Categories: ,

Description

Technical specifications

Welding range 25 – 125 mm PN 2.5 – PN 16
Voltage 230 V 50 Hz
Poténcia Machine 1.6 kW 6.9 A
Heating element IP 54 0.875 kW
Refresher IP 20 0.710 kW
DIMENSIONS
Basic Machine Cms. 52x26x36
Refresher Cms. 47x28x6.7
Heating element Cms. 45x25x7
WEIGHT
Basic machine 16 kg
Refresher 3 kg
Mirror and Refractor Support 3 kg
Set of Diam Inserts. 25 – 110mm 11 kg
Clamp 2 kg
Complete set of Inserts 2 kg
Lide holder plate 1.5 kg
Transport box 16 kg

Realizar consulta..

Additional information

Gama de soldadura
Potencia
Automática
Homologada Gas
Propulsada
Hidráulica o Manual
